بایگانی برچسب: Simulation SPH explosion inside the RC column

Simulation SPH explosion over a composite column(Steel cover+Concrete+CFRP I shape beam) in Abaqus has been investigated in the present tutorial. The steel cover and CFRP I shape beam are modeled as three-dimensional shell parts. The concrete and TNT are modeled as three-dimensional solid parts. You can see a figure of ...

In this tutorial, the Simulation of ceramic plates as shielding for concrete blocks against projectile penetration(SPH method) has been done. The ceramic plate and Ultra-High-Performance-Concrete are modeled as three-dimensional solid parts. The bullet is modeled as a solid part. You can see a figure of the assembled parts below In ...

In this tutorial the explosion simulation near the reinforced concrete wall with green composite-SPH method- has been investigated. The TNT part is modeled as a three-dimensional solid part. The concrete wall or slab is modeled as three-dimensional solid part, the green composite part with eight layers is modeld as three-dimensional ...

In this tutorial, the Simulation SPH explosion near RC slab by using CDP model couple with strain rate in Abaqus  has been investigated. The RC slab is modeled as a three-dimensional solid part. The steel bars are modeled as three-dimensional wire part. The TNT is modeled as a three-dimensional solid ...

In this tutorial, the Simulation SPH explosion inside the RC column with outer steel box cover in Abaqus has been investigated. The concrete and TNT are modeled as three-dimensional solid parts. The steel box is modeled as a three-dimensional shell part. The steel bars and strips are modeled as three-dimensional ...
