The numerical simulation on the high-low velocity impact response of GLAREs in Abaqus software has been investigated. The model contains metal aluminum layers and glass fiber. You can see a figure of the assembled parts below In recent decades, the demand for high‐performance materials has increased significantly in various sectors ...

In this tutorial, the Simulation high-velocity impact on the Aluminum-Bamboo sandwich panel in Abaqus has been done. The aluminum plate is modeled as a three-dimensional solid part. The bamboo plate is modeled as a shell part with thirty two layers with different fiber angle. The projectile is modeled as a ...

In this tutorial, the Simulation rigid impact to the composite panel(CFRP+TPU+AL) in Abaqus-Damage investigation – has been studied. The CFRP part is modeled as a shell part with eight layers. The Thermoplastic polyurethane is modeled as a three-dimensional solid part. The Aluminum part is modeled as a three-dimensional solid part. ...

In this tutorial, the High-velocity impact of a bullet on the RC panel- Paper validation- is investigated. The dimensions are extracted from the paper. The concrete slab is modeled as a three-dimensional solid part. The steel reinforcements are modeled as three-dimensional wire parts. The bullet is modeled as a discrete ...

In this video Simulation high velocity bullet impact to three layers plate in Abaqus has been investigated. To model all part three dimensional space was used. Ductile and Shear damage with evolution for modeling steel behavior, Johnson-Cook damage and plasticity for modeling aluminium behavior and Ductile damage couple with Drucker-Prager plasticity for ...

In this video soil impact to the metal plate in Abaqus by using SPH method has been simulated. The soil is modeled as three dimensional part with elastic–plastic behavior and smooth particle hydrodynamic formulation. Coulomb-Mohr plasticity is implanted for soil. To definite particle element edit input file capability has been ...

This video explains high velocity impact of a bullet to the concrete wall step by step.Bullet is modeled as a 3 dimensional part with rigid property and concrete as a 3 dimensional part with Johnson-Cook plasticity and damage for predicting fracture area that happened during the analysis.Johnson-Cook  material has better ...

This is full English video step by step explain simulation high velocity impact of a steel projectile into the ceramic-composite plate in Abaqus . During the analysis the projectile penetrate into the plate and removed ceramic elements but the composite elements had a good performance against the steel rod penetration ...

This is full English video step by step explain simulation high velocity impact of a projectile into the concrete wall .The concrete part is modeled as three dimensional part. CDP or concrete damage plasticity is used to model the tensile and compressive damage of concrete slab. The projectile is modeled ...
