بایگانی برچسب: abaqus ductile damage modeling

In this tutorial, the Simulation drilling process of the aluminum alloy in Abaqus has been studied. The tool is modeled as a rigid shell part and the aluminum part is modeled as a three-dimensional solid part. You can see a figure of the assembled parts below To model aluminum behavior, ...

In this tutorial, the Simulation dynamic tensile test of an aluminum piece by using ductile, shear, and MSFLD damage criterion in Abaqus has been studied. The aluminum part is modeled as a three-dimensional solid part. You can see a figure of the assembled below The aluminum alloys may fail due ...

In this tutorial, Simulation of Stud Connected Steel-Concrete Composite Girders Subjected to four-point bending in Abaqus has been studied. The performance of steel-concrete composite (SCC) girders for static and dynamic loads depends significantly on the force transfer mechanism at the interface between steel beam and concrete. Stud connected SCC girders consist ...

In this tutorial, the Simulation shear failure of two steel plates with bolt connection in Abaqus has been investigated. The steel plates are modeled as a three-dimensional solid part The bolts with different sizes are modeled as a three-dimensional solid part. You can see a figure of the assembled part ...

In this tutorial, the Simulation CEL explosion inside the steel pipe embedded in the depth of soil in Abaqus has been investigated. The pipe is modeled as a three-dimensional shell part. The TNT, soil, and air are modeled as a three-dimensional solid part. The Eulerian part is model as a ...

In this tutorial, simulation of bolt failure in the bolted joints in Abaqus has been done. The two steel plates and the bolt are modeled as a three-dimensional solid part. You can see a figure of the assembled parts at below To obtain failure, the ductile damage criterion is used ...

In this tutorial, the Simulation flexural response of aluminum alloy profile in Abaqus- Damage investigation- has been studied. Aluminum alloys are used across a range of structural engineering applications, with square and rectangular hollow sections being a popular cross-section shape. This can be particularly beneficial for enhancing resistance to local ...

In this tutorial, Simulation three points bending of the foam-filled aluminum tube under dynamic load in Abaqus has been studied. The foam is modeled as a three-dimensional solid part and the aluminum tube is modeled as a three-dimensional shell part. Three rigid bodies are used as a pusher and supporters. You ...

In this tutorial, Simulation cyclic loading over a steel column with stiffeners in Abaqus-Damage investigation- has been studied. The box column is modeled as a three-dimensional shell part and the stiffener is modeled as a planar shell part. You can see a figure of assembled part at below The stiffeners ...

In this tutorial dynamic simulation of tensile test of a steel piece under axial deformation in Abaqus has been investigated. A three dimensional part like below figure is used to model steel geometry To model failure behavior of the steel piece shear and ductile damage with evolution, isotropic plasticity with ...
